Nozzle Ring VIV07-042 for 725390, 736554, 743250 GTA3782VA, GT3782VA, GT3788VA Turbocharger

Dimensions:
external diameter : 138.9-139 mm
internal diameter : 95.5-95.55 mm
Mounting plate Height : 5.6±0.02 mm
Blades Height : 13.2 mm
Blades Quantity : 9

Material List
Guide wheel SUS303Cu
Distance shaft SUS316
Distance sleeve SUS303Cu
Vane HK30
Lining plate GX40CrNISi22-9
Shift fork 310S
Mounting plate GX40CrNISi22-9
Lobulated ring 310S

Application:

Turbo Model : GTA3782VA, GT3782VA, GT3788VA

Turbochargers
Part No. : 725390-0001/2/3/5 725390-5003S
OE No. : 3C3Z6K682CCRM, 1837984C93, 1837984C91, 1837984C94, 1832160C91, 1840054C98, 1846764C91, 1840054C97

Part No. : 736554-0001/2/3/4/5/6/7/8/11 736554-5011S 736554-9011
OE No. : 8973868232 , 8973878962 , 8973527060 , 8973527061 , 897352706C , 8973527064 8973527065 , 8973527066 , 8973527067 , 97387896, 8-97386-8232 , 8-97387-8962 , 8-97352-7060 , 8-97352-7061 , 8-97352-706C , 8-97352-7064 8-97352-7065 , 8-97352-7066 , 8-97352-7067

Part No. : 743250-0002,743250-0004, 743250-5002S, 743250-5004S
OE No. : 18254480C91, 1843761C94, 1845178C94, 1846765C91, 1845178C95, 1832255C91, MCM013587
