VNT Nozzle Ring VIV07-011VNT for 49131-06003/4/5/6/7/8 TD03 Turbocharger

Dimensions:
external diameter : 71.4 mm
internal diameter : 36.1 +0.10 mm
Mounting plate Height : 24 mm
Blades Angle : 77.7
Blades Height : 6.49-6.53 mm
Blades Quantity : 13

Material List
Guide wheel SUS303Cu
Distance shaft SUS316
Distance sleeve SUS303Cu
Vane HK30
Lining plate GX40CrNISi22-9
Shift fork 310S
Mounting plate GX40CrNISi22-9
Lobulated ring 310S

Application:

Turbo Model :
TD03

Turbochargers
Part No. : 49131-06003, 49131-06004, 49131-06005, 49131-06006, 49131-06007, 49131-06008
OE No. : 860070, 8973000923, 97300092, 8973000926, 8973000925, 860147, 860128
