VNT Nozzle Ring VIV07-009VNT for 454135-0005, 454135-0010, 709838, 710415, 711009, 715910, 721204, 751243, 757608, 767720, 769708 GT2052V/GT2256V/GT2056V Turbocharger

Dimensions:
external diameter : 89.7 mm
internal diameter : 55 mm
Mounting plate Height : 8.65±0.05 mm
Blades Angle : 57
Blades Height : 7.5 ±0.03 mm
Blades Quantity :13

Material List
Guide wheel SUS303Cu
Distance shaft SUS316
Distance sleeve SUS303Cu
Vane HK30
Lining plate GX40CrNISi22-9
Shift fork 310S
Mounting plate GX40CrNISi22-9
Lobulated ring 310S

Application:

Turbo Model : GT2052V/GT2256V/GT2056V

Turbochargers
Part No. : 454135-5010S
OE No. : 059145701F 059145701K 059145701E 059145701D 059145701S

Part No. : 709838-0001/2/3/4/5 709838-5005S
OE No. : 6120960399, A6120960399

Part No. : 710415-0001/2/3 710415-5003S
OE No. : 77814359, 7780199D, 860049, 116577814359, 11657780199D, 1165860049, 7781434, 7781435, 11657781434, 11657781435, 7780199C, 11657780199C

Part No. : 711009-0001 711009-5002S 711009-9003S
OE No. : 6120960499, A6120960499, A6120960999, 6120960999

Part No. : 715910-0001/2 715910-5002S
OE No. : 6120960599, A6120960599

Part No. : 721204-0001 721204-5001S
OE No. : 062145701A, 9.0529.20.1.0071-04, 9.0529.20.1.0071-02, 90529201007104, 90529201007106, 90529201007102, 90529201009202

Part No. : 751243-5002S
OE No. : 14411EB300, 14411-EB300

Part No. : 743507-5009S 757608-5001S 765155-5007S
OE No. : 6420900280, A6420900280, A6420901480, 6420901480, 6420900780, 6420904780, 6420905980, A6420900780, A6420904780, A6420905980, 68037207AA, A68037207AA, A6420902980, 6420902980, A6420908780, 6420900080, A6420900080, 6420901480, A6420901480, A6420901490, 6420901490, A6420908780, 6420908780, A642090598080, 642090598080, 642090708088, 642- 090-70-80-6, 642 090 708 088

Part No. : 479001-5001S 767720-0001 769708-0001
OE No. : 1420195013, 14201-95013, 14201 00Z0D, 14201 00Z3B, 14201-25507, 14201-90005, 14201-95010, 14201-96601, 14201-96671, 14201-C8700, 14201-L2400, 14201-L6001, 14201-L9000, 14201-Z5566, 1420100Z3A, 1420100Z4C, 1420100Z61, 1420100Z62, 1420195013, 1420196606, 1420196607, 14411-01D01, 14411-03D00, 14411-05D00, 14411-09D60, 14411-3S900, 14411-51N00, 14411-62T00, 14411-69T61, 14411-69T91, 14411-9S000, 14411-9X800, 14411-D8801, 14411-D8802, 14411-EB70A, 14411-EB70B, 14411-EC00B, 14411-EC00C, 14411-WF500, 14411EB320, 14411EB71C, 14411EC00C, 14411MA70A, 4670342, J4670341
