VNT Nozzle Ring VIV07-007VNT for 454161, 454231, 454232, 700447, 701855, 713672, 768331 GT1749V/GT1549V/GT1544V Turbocharger

Dimensions:
external diameter : 81.4-81.5 mm
internal diameter : 45.3 +0.10 mm
Mounting plate Height : 8.65±0.05
Blades Angle : 55
Blades Height : 5.29-5.33 mm
Blades Quantity : 9

Material List
Guide wheel SUS303Cu
Distance shaft SUS316
Distance sleeve SUS303Cu
Vane HK30
Lining plate GX40CrNISi22-9
Shift fork 310S
Mounting plate GX40CrNISi22-9
Lobulated ring 310S

Application:

Turbo Model :

Turbochargers
Part No. : 454161-0001 454161-5003S
OE No. : 028145702D, 028145702D, 028145702DX, 028145702DV

Part No. : 454231-0001/3/4 454231-5012S 454231-9012S
OE No. : 028145702H, 028145702HV225, 028145702HV500, 028145702HX, 028145702HV

Part No. : 454232-0001/3/4/5 768329-5001S 768331-5002S
OE No. : 03G253014R, 03G253014L, 03G253016L, 038253019C, 038253019CX, 038253019CV, 038253019A, 038253019AX, 038253019AV, 03G253016K, 03G253014R, 03G253016L, 038253019A, 038253019D, 038253019AV200, 03G253016K, 038253019CV225, 038253019CV500, 03G253016N

Part No. : 701855-0001/3/5
OE No. : 1031116, 1094742, 028145702P, 028145702PV500, 95VW9G438BA

Part No. : 713672-0002/3/4/5 713672-5006S 713672-9006S
OE No. : 038253019C, 038253019CV500, 03G253016N, 038253019CV225

Part No. : 700447-0001/2/3/4/5/6/7/8 700447-5008S

OE No. : 2247297F, 2247297G, 2247297H, 2247901H, 2247905H, 2248901G, 2248905G, 11652247297F, 11652247297G, 11652247297H, 11652247901H, 11652247905H, 11652248901G, 11652248905G, 2247901104, 11652247901104
